Drake SW8
| Type: |
HF/VHF receiver |
| Frequency Range: |
0.1-30 / 87-108 / 118-137 MHz |
| Mode: |
AM/AM SYNC/SSB/WFM |
| Sensitivity: |
N/A |
| Selectivity: |
N/A |
| Image rejection: |
N/A |
| Voltage: |
7-10 VDC external or 6*LR20 internal |
| Current Drain: |
Max 1 A |
| Aerial Input: |
50/300 ohms |
| Dimensions (W*H*D): |
292 x 133 x 330 mm |
| Weight: |
? Kg |
| Manufactured: |
USA: 1994-1998 |
| Other: |
|
| Related Documents: |
User Manual (496 Kb) |
 |
